304 stainless steel floor plate, also known as "tread plate" or "diamond plate", is an excellent candidate for most processing techniques as well as both indoor and outdoor applications. This product has a textured dull grey finish with a raised diamond pattern to provide all around traction.
Stainless steel floor plate has a hot rolled, annealed and pickled (HRAP) finished surface. Its high strength properties and excellent corrosion resistance make it the perfect candidate for catwalks, trench covers, walkways, and ornamental projects. ASTM A793 is the standard specification for stainless steel rolled floor plate.
| Alloy | ASTM Standard | Characteristics |
|---|---|---|
| 304 | ASTM A793 | Good welding & fair machining. Excellent corrosion resistance for versatile use. |
| CHEMICAL COMPOSITION | |
|---|---|
| Element | Percentage (%) |
| Carbon (C) | 0.08 max |
| Iron (Fe) | 66.34 - 74 |
| Manganese (Mn) | 2 max |
| Nickel (Ni) | 8 - 10.5 |
| Phosphorus (P) | 0.045 max |
| Sulfur (S) | 0.03 max |
| Silicon (Si) | 1 max |
| Chromium (Cr) | 18 - 20 |
| MECHANICAL PROPERTIES | ||
|---|---|---|
| Property | Imperial | Metric |
| Density | 0.289 lb/in³ | 8.0 g/cc |
| Ultimate Tensile Strength | 73,200 psi | 310 MPa |
| Yield Tensile Strength | 31,200 psi | 276 MPa |
| Melting Point | 2,550 - 2,651°F | 1,400 - 1,455°C |
| Thickness | Width | Length | Weight (lbs/ft) |
|---|---|---|---|
| 1/8" | 48.00" | 120.00" | 6.150 |
| 3/16" | 48.00" | 120.00" | 8.700 |
| 3/16" | 60.00" | 120.00" | 8.700 |
Our supply includes high-purity coils, sheets, plates, rods, bars, tubes, and strips. These products are critical in industries such as automobile engineering, railway transportation, aerospace, petrochemical, energy, offshore, and pressure vessel manufacturing.
